Description
Experience the comfort, convenience and versatility of a zero-turn mower backed by the quality and performance you expect from an Ariens. The intuitive controls of the Edge help you maneuver in, around and through smaller yards with a fast, clean-cut. Get your perfectly manicured lawn and get back to your busy day faster with Ariens’ legendary zero-turn engineering in your garage.
- 21.5 hp, 726cc V-Twin Kawasaki FR series engine is a commercial grade power plant that features cast iron cylinder liners for long life, automatic compression release for easy starting and internally vented carburetor for better fuel management
- 52 inch wide 11 gauge steel fabricated deck is commercial style with advanced airflow for exceptional cutting performance
- Twin EZT hydrostatic Transaxles designed to deliver responsive, smooth, effortless control with speeds of 6 mph forward and 3 mph in reverse
Product specifications
Deck Gauge
11
Cut Width(cm)
132.08
Cut Width(mm)
1320.8
Engine Oil Capacity(g)
1814.368
Warranty
2-year limited or 150 hours
Engine Horsepower
21.5
Cutting Range/Yard Size (Acres)
1-2
Assembled Weight(kg)
311.1696
Cut Width(in)
52
Assembled Weight(lbs.)
551
Attachment Compatible
Rear
Engine Displacement (Cu. Centimeters)
726
Blade Engagement Type (PTO)
Electric
Engine Brand
Kawasaki
Discharge Location
Side
Leaf Bag Included
No
Ammeter
No
Cruise Control
No
Bagger Capable
Yes
Differential
Independent motor
Minimum Cutting Height(in)
1.5
Front Wheel Size
11-in
Maximum Cutting Height(cm)
11.43
Maximum Cutting Height(mm)
114.3
Overall Length(cm)
142.875
Overall Length(mm)
1428.75
Overall Width with Deck(cm)
193.675
Overall Width with Deck(mm)
1936.75
Fuel Capacity(gal)
2.0
Rear Wheel Size
18-in
Maximum Reverse Speed(MPH)
3
Number of Blades
3
Number of Deck/Anti-Scalp Wheels
2
Minimum Cutting Height(cm)
3.81
Minimum Cutting Height(mm)
38.1
Maximum Cutting Height(in)
4.5
Overall Length(in)
68
Maximum Forward Speed(MPH)
6
Engine Oil Capacity(oz.)
70.4
Number of Deck Positions
7
Fuel Capacity(l)
7.5708
Overall Width with Deck(in)
64.2
Front Axle
Steel
Steering Type
Dual lap bar
Engine Type
V-twin
Hour Meter Type
Meter only
Fuel Type
Gas
Seat Type
High-back
Engine Series
FR651V
Grease Fittings
No
Headlight(s)
No
Safety Listing
Not safety listed
Engine Oil Included
Yes
Operator-Controlled Mow-in-Reverse
Yes
Mulching Capable
Yes (kit sold separately)
Recommended for Terrain Type
Flat with obstacles
Series Name
Edge
File/Certification Number
N/A
Oil Filter Type
Spin-on
Transmission Type
Dual hydrostatic
Type
Zero-turn
Tire Type
NHS – Not for Highway Service
