Description
This curb mount skylight is the preferred skylight choice in Canada for any type of roof; primarily for use on tile, shingle or wood shake roofs. This model is the optimum choice for long-lasting, trouble-free installation. Other skylight types include built-in wood curbs for double the cost. Ideal for rooms that are south facing or require softer light and it provides the ideal balance of solar heat gain control and visible light transmission.
- Columbia Skylights utilizes maintenance-free white vinyl base frame with an integrated 4-sided gutter to collect any condensation caused by Canada’s extreme climate.
- Designed for inside curb dimension of 22.5-in x 58.5-in (outside curb 25.5-in x 61.5-in)
- Recommended use of aluminum flashing kit model FKCM2876
- Durable, low maintenance exterior aluminum frame with grey baked enamel
- LoE3 bronze tempered glass offers the ideal balance between solar heat gain control and visible light transmission and is perfect for south-facing skylights
Product specifications
Actual Width(in)
28
Outside Frame/Curb Height(in)
61.5
Rough Opening Height(in)
58.5
Rough Opening Width(in)
22.5
Actual Height(in)
64
Actual Length(in)
3.25
Outside Frame/Curb Width(in)
25.5
Rough Opening Length(in)
5.5
Exterior Material
Aluminum
Shade/Blind Power Source
N/A
Remote Control Included
No
Type
Skylight
Shade/Blind Style
N/A
Color/Finish Family
Grey
ENERGY STAR Certified North/Central Zone
Yes
ENERGY STAR Certified South/Central Zone
Yes
Interior Frame Material
Vinyl
Glass Type
Tempered glass over tempered glass
Glazing Type
Tempered
App Compatibility
No
Shade/Blind Color
N/A
Shade/Blind Operation
N/A
Blinds Included
No
Flashing Included
No
ENERGY STAR Certified Southern Zone
Yes
Installation Type
Curb mount
Warranty
20-year limited
Frame Color/Finish
Grey
Hardware Included
No
Glass Insulation
Low-E argon
ENERGY STAR Certified Northern Zone
Yes
Glass Tint
No
Skylight Style
Fixed
